RQ-4 Global Hawk - PDF - 1:10 Scale - WS:157.45in - Downloadable Plans. (Stock Code: 0029)

$294.99
No tax
Download a full-size sample in attachments, right below.
Quantity
In-stock



All plans are registered at www.workscopyright.com and cannot be resold.

  Security policy

I will always send a backup copy to your email. Search in SpamBox also.

  Download Policy

Payment approved, a download link is sent to your email. You have 3 authorized attempts.

  Return policy

Digital files and cannot be exchanged or returned, because the customer will always have a copy.

  DXF

DXF files are the simple conversion of the DWG file to DXF.

Downloadable Plans.

RQ-4 Global Hawk UAV - PDF - 1:10 Scale - WS: 157.45pol - Details

Plans in 1:1 scale
Balsa Wood Construction coated fiber
Indicated Engine: P-60 Turbine
Profile of the wing: Wort FX05-H-126
Wingspan: 399,92 cm (157,45")
Lenght: 145,5 cm (57,28")
Semi-coated composite structure with fiber
Accepts complete system of autonomous navigation

Three wing panels removable for transport.
System Aileron / Rudder mixed with aileron wing
Aerodynamic brake

Requires good takeoff on runway.
All formers and ribs in the plans drawn.

Compatible with Corel

Size: 1.51 MB (1,589,248 bytes)
Requires WinRar to decompress.

[ PDF format ]

Not following pictures, assembly instructions or CD.


To purchase a navigation system Click here.

(Stock Code: 0029)
90000 Items

Download

FREE SAMPLE

Click above and see an example in full size.

Download (364.43k)
