Aermacchi MB-326 Xavante - PDF - EDF120 - 1:5 Scale - Downloadable Plans. (Stock Code: 0341)
|Download a full-size sample in attachments, right below.|
Product customizationDon't forget to save your customization to be able to add to cart
All plans are registered at www.workscopyright.com and cannot be resold.
I will always send a backup copy to your email. Search in SpamBox also.
Payment approved, a download link is sent to your email. You have 3 authorized attempts.
Digital files and cannot be exchanged or returned, because the customer will always have a copy.
DXF files are the simple conversion of the DWG file to DXF.
Aermacchi MB-326 Xavante - 1:5 Scale - PDF - EDF120 - Details
Plans in 1:1 scale
Conventional balsa construction.
Wingspan: 214cm (84")
Lenght: 208cm (82")
Engine: EDF: JTM 120 / TP-POWER 950kV / recom. Lipo: 12S / Amp draw: 180A / stat. thrust: 9kg (19.8 lbs)
Radio: 5~8 ch
Includes wing tip tanks
Includes retractable landing gear.
Includes tanks under the wings, may be released by radio.
Not included article, photos or assembly instructions
Size: 1.53 MB (1,609,728 bytes)
Requires WinRar to decompress.
[ PDF Format ]
Excessive movement of the ailerons and elevator, causing the instability of this model.
We recommend for the first tests, a limit of ailerons 6mm up and down.
In the elevator recommend 12mm up and 12mm down at most.
After the first test flights, you can gradually change the setting for optimum performance.
