Embraer ERJ-145 - DXF - 1:15.8 Scale - 2xEDF60 - Downloadable Plans. (Stock Code: 0339)
|Download a full-size sample in attachments, right below.|
All plans are registered at www.workscopyright.com and cannot be resold.
I will always send a backup copy to your email. Search in SpamBox also.
Payment approved, a download link is sent to your email. You have 3 authorized attempts.
Digital files and cannot be exchanged or returned, because the customer will always have a copy.
DXF files are the simple conversion of the DWG file to DXF.
Embraer ERJ-145 - DXF - 1:15.8 Scale - 2 x EDF60 - Details
Plans in 1:1 scale
Conventional balsa construction.
WingSpan: 127 cm (50")
Lenght: 178.05 cm (70.2")
Engine: 2 x EDF60
Requires retractable landing gear.
Dismountable horizontal stabilizer.
Dismountable wing in two panels with bayonet carbon fiber tube
Aperture cap on the back of the fuselage between the EDF
Access cover to the nose landing gear
Access covers on the cowls of each EDF turbine
Does not include photos, magazine article or manual assembly.
Size: 2.13 MB (2,240,512 bytes)
Requires WinRar to decompress.
[ DXF format ]
