Embraer EWRJ-145 AEW-C - PDF - 1:10.28 Scale - Downloadable Plans. (Stock Code: 0335)
$70.00
2
 |
Download a full-size sample in attachments, right below. |
All plans are registered at www.workscopyright.com and cannot be resold.
Security policy
I will always send a backup copy to your email. Search in SpamBox also.
Download Policy
Payment approved, a download link is sent to your email. You have 3 authorized attempts.
Return policy
Digital files and cannot be exchanged or returned, because the customer will always have a copy.
DXF
DXF files are the simple conversion of the DWG file to DXF.
Downloadable Plans.
Embraer ERJ-145 AEW&C - 1:10.28 Scale - PDF - Details
Plans in 1:1 scale
Conventional balsa construction.
WingSpan: 204.5 cm (80.51")
Lenght: 287.13 cm (113")
Engine: 2 x EDF90 minimum
Radio: 5-7 ch
Editable in CorelDRAW Graphics Suite, Photoshop CS6 Extended and others
Single-piece detachable vertical stabilizer
Demountable wing in 2 panels joined by carbon fiber tubes
Radar can be removed and relocated at any time effortlessly.
Optional retractable landing gear
Easy-to-build balsa wood winglets include full design. Coat the curve of the union with the wing with nylon and glue.
Does not include photos, magazine article or manual assembly.
Size: 2.30 MB (2,420,736 bytes)
Requires WinRar to decompress.
[ PDF format ]
(Stock Code: 0335)
